HITSZPM-550
Products
Main Features:
-
Fully Touch-screen controlled (7.00")
-
Robust and maintenance free design
-
Four synchronized servos
-
Tension Control
-
Edge guider/ web liner
-
Air shaft
-
Programmable conveyor
-
Double stroke cutter programme for corner cut pouches
Machine is divided in following section:
- Conveyor
- Cutter
- Registration
- Slitting
- Print/Mark section
- Punching
- Longitudinal sealing/ cooling
- Dancer
- Three side sealing
- Stand-up sealing/ zipper sealing
- Gussate forming
- Center sealing
- Tube forming
- Triangle folder
- Unwinder
- Edge guider
Production Variety:
- Six side seal pouches
- Three side seal pouches
- Center seal pouches
- Perphoration pouches
- Gussete pouches
- Sheet Cutting
- D-punch Bag
- Retort Pouches
- Corner cut pouches
Specifications:
max. min.
paper size(mm) 1000 100
pouch length(mm) 500 50
roll diameter(mm) 600 100
gussate deep(mm) 75 15
double stroke length(mm) 10 3
machine speed* (cpm) 150 10
-
Auto-tune PID TEMPERATURE CONTROLLER
-
Imported motors and gear boxes
-
Imported Photo sensor for print mark registration
-
all Pneumatic products are from Festo
M/c Code: HICPMP-500
MFG. OF: ALL TYPE OF POUCH & BAG MAKING MACHINERY
Machine Feature:
