Paper Sheet Cutting MachMachine-400

Picture Gallery

Watch Video

E-Catalogue

Main Features:

  • Fully Touch-screen controlled (7.00")

  • Robust and maintenance free design

  • Four synchronized servos

  • Tension Control

  • Edge guider/ web liner

  • Air shaft

  • Programmable conveyor

  • Double stroke cutter programme for corner cut pouches

Machine is divided in following section:

  • Conveyor ​
  • Cutter
  • Slitting
  • Print/Mark section
  • Dancer
  • Unwinder
  • Edge guider
  • Tension control
  • Air-shaft

Production Variety:



  • Paper sheet cutting
  • Napkin cutting
  • Label cutting

Specifications:

                                                max.     min.

paper size(mm)                          1000       50

sheet length(mm)                         500       25

roll diameter(mm)                       1000     100

double stroke length(mm)               10         3

machine speed* (cpm)                  150       10



  • Imported motors and gear boxes

  • Imported Photo sensor for print mark registration

  • all Pneumatic products are from Festo

M/c Code: HIPSCMP-400

MFG. OF: ALL TYPE OF POUCH & BAG MAKING MACHINERY

Machine Feature:
