- ROBUST DESIGN
- TOUCH-SCREEN CONTROLLED
- AUTO-STACKER
- HIGH SPEED PRODUCTION
- MORE PRODUCTION VARIETY
HITSZPM-550
Products
Machine is divided in following section:
- Conveyor
- Cutter
- Slitting
- Print/Mark section
- Punching
- Longitudinal sealing/ cooling
- Inline sealing/ cooling
- Stand-up sealing/ zipper sealing
- Gussate forming
- Punching for stand-up pouches
- Two unwinder for extra insertion flap
- Dancer
- Registration
- Triangle
- Unwinder
Production Variety:
- Two Line Stand- up Pouches
(with or without zipper)
- Three side seal pouches
- D-punch Bags
- Spout Pouches
- Retort Pouches
- Corner cut pouches
Specifications:
max. min.
paper size(mm) 1000 100
pouch length(mm) 500 50
standup pouch length(mm) 350 50
roll diameter(mm) 600 100
gussate deep(mm) 100 25
double stroke length(mm) 10 3
machine speed* (cpm) 144 25
-
Auto-tune PID TEMP. CONTROLLER
-
Imported motors and gear boxes
-
Dyna-spede tension controller
-
Imported Photo sensor for print mark registration
-
all Pneumatic products are from Festo
M/c Code: HITSZPM-500
Main Features:
-
Fully Touch-screen controlled (7.00")
-
Robust and maintenance free design
-
Four synchronized servos
-
Tension Control
-
Edge guider/ web liner
-
Air shaft
-
Programmable conveyor
-
Double stroke cutter programme for corner cut pouches
MFG. OF: ALL TYPE OF POUCH & BAG MAKING MACHINERY
Machine Feature:
